explosion proof light e27 water proof light 2x18w t8 exproof led linear lamp light
• quick, simple and easy installation
• optional installation of lampshade on hinges during fluorescent lamp replacement
• high resistance to a corrosive industrial environment,
• high luminous efficacy- 0.9
• high-quality ignition systems
• UV-resistant CONSTRUCTIONBHD51 series of explosion-proof linear light is designed and manufactured with a small size, light weight, long life,
pollution-free, maintenance-free, safe, energy saving, durable and environmental-friendly Explosion-proof LED linear light.
Housing: high light transmittance PC material , the strength of more than 4J, can reduce the damage to the light in the abnormal operation.
Diffuser: PC polycarbonate plastic
Gasket(waterproof O-ring): Nitrile rubber, good aging and corrosion resistance.
Light shell: Aluminum alloy high pressure die-casting, with good microstructure, hardness and wear resistance
Fasteners: STS304 stainless steel with high corrosion resistance and high strength
The light fitting Accessories and lamp housing split structure design, easy installation and maintenance; selection of imported light source chip energy saving, environmental protection, high brightness, life expectancy up to 100,000 hours. SUITABLE FOR:Explosion-safe for gas and dust Suitable for Zone 2 and Zone 22 CE compliance in accordance to ATEX
Ex mark: II3G Ex nR IIC T6 Gc, II 3D Ex tc IIIC T80ºC Dc IP66, 94/9/EX(ATEX)CENELEC:EN 60079-0, EN 60079-15, EN 60079-31
(1)DC and emergency light available on special request
(2)Warm white Neutral White and cool white available indent only
***AC Current rating at 85 ~ 265VAC
***3-D heat dissipation Housing
Professional heat dissipation structure design. Modular heatsink with perfect structure and inside airflow channels maximing the 3D heat dissipation.
***Compressed Fins Technology
Creative compressed Fins tech. rivets the heatpipe to heatsink closely, minimizing the heat resistnace, greatly improving the cooling. It is also much lighter.
***Patented HDT technology
Highly efficient heatpipes contact the heat heat source firmly, maximing the performance of heatpipe and cooling effect.
Composed of 4 main components: Heat Sink / LED Module / Optical System / Driver. Electrical components are RoHS compliant. IP66 sealed light engines. LEDs tested by ISO 17025-2005 accredited lab in accordance with IESNA LM-80 guidelines extrapolations in accordance with IESNA TM-21. Metal core board ensures greater heat transfer and longer lifespan.
Anodized 6063-T5 Aluminum for a high resistance to corrosion, designed to ensure high efficacy and superior cooling by natural vertical convection. Air flow pattern always close to LEDs and driver optimizing their efficiency and life. Product does not use any cooling device with moving parts (only passive cooling).
Composed of high performance white LEDs. Color temperature as per ANSI/NEMA bin Neutral White, 4000 Kelvin nominal (3985 +/-275K or 3710K to 4260K), CRI 70 Min.
***Optical System beam angle reflectors
Flake designed high-purity aluminum reflectors 30°, 60°,90°,110°with PC cover option to meet professional light distribution, to adapt to different situations.The reflector is made of pure aluminium(99.8%) which is anti-oxidation and unfading in colour, ensuring the reflection..
With Meanwell TUV driver,high power factor of 90% min. Electronic driver, operating range 50/60 Hz. Auto adjusting universal voltage input from 85 to 277 VAC or 347 to 480 VAC rated for both application line to line or line to neutral, ClassI, THD of 20% max. 0-10V dimming driver included, dimming leads pre-wired to controls except when DD option is selected. The currentsupplying the LEDs will be reduced by the driver if the driver experiences internal overheating as a protection to the LEDs and the electrical components. Output is protected from short circuits, voltage overload and current overload. Automatic recovery after correction. Standard built in driver surge protection of 2.5kV (min).
***EX-PROOF LIGHTING FIXTURES Specification
Lamp Luminous Efficiency(lm/w)
Color Rendering Index(Ra)
Lighting solutions service
Lighting and circuitry design, DIALux evo layout, LitePro DLX layout, Agi32 layout, auto CAD layout, Project Installation
Working Time (hours)
Lamp Luminous Flux(lm)
Explosion Proof Light
II 3G Ex nR IIC T6 Gc/II3D Ex tD IIIC T80℃ Dc
Zone 2&22, Class I Division 2, Class II Division 2
Philip 3030 led
source: Individual lighting, floodlighting, compact lights, and emergency lighting. From fluorescent tubes to the durable
high-efficiency LED light sources, from the articles of plastic over stainless steel to aluminium die-cast bodies -Huading's
lighting range covers almost every application. A wide range of accessories as well as extensive services for designing lightingsystems are also available.
* Lights for every application
* Wide range of accessories
* Extensive services
* Oil & gas
* Pharmaceutical industry
* Chemical industry
* Mechanical engineering/OEM
